Description

500mm Easy Fit Clickloc Polycarbonate Sheet Clear - Your Hassle-Free Roofing Solution

Transform your outdoor spaces with the innovative Clickloc system, featuring a 16mm thick polycarbonate roofing sheet designed for the ultimate DIY installation ease. Perfect for carports, canopies, verandas, and pergolas, this system eliminates the need for complex glazing bars, offering a straightforward, click-together solution for an instant roof.

Key Features:

1. Easy Installation:

DIY-Friendly: Designed with simplicity in mind, these panels require no special tools or professional help. Cut to size, screw in place with the clickloc channel washer, click together, and you're done!
No Glazing Bars Needed: The easy-fit panels click together seamlessly, providing a clean and professional finish without the complexity of traditional systems.

2. Durable and Long-Lasting: Material:

Made from impact-resistant, lightweight polycarbonate, these panels are built to withstand the elements while remaining easy to handle.
UV Protection: Each panel comes with a UV protection layer on the top surface, ensuring it stays in excellent condition for years, protecting against discoloration and degradation.
Finish: Frosted clear and frosted opal finishes offer a stylish look while diffusing light beautifully into your space.

3. High Performance:

Sheet Thickness / Type: 16mm 5 Wall X-Structure provides a robust structure that is both lightweight and strong.
Thermal Efficiency: With a U-Value of 2.0W/m²K, these panels offer good thermal insulation, keeping your space comfortable year-round.
Light Transmission: The frosted clear panels allow for 66% light transmission, creating a bright yet sheltered outdoor area.

4. Specifications for Spanning:

1000N/m² Load: Achieve purlin centres of up to 800mm for robust support.
750N/m² Load: Suitable for purlin centres of up to 1000mm.
500N/m² Load: Allows for wider purlin centres of up to 1200mm, offering flexibility in design.
Minimum Roof Pitch: Designed to be effective with a minimal slope of 5°, ensuring efficient water runoff.

Installation Tips:

Preparation: Measure and plan your project area carefully before cutting the panels to ensure a precise fit.
Cutting: Use appropriate tools to cut the panels cleanly to your required length.
Securing: Ensure the clickloc channel washers are correctly positioned to secure the panels effectively..
Click and Lock: Align the panels carefully and click them into place, checking for a secure fit before moving on to the next panel.

The 500mm Easy Fit Clickloc Polycarbonate Sheet Clear offers a blend of simplicity, durability, and aesthetic appeal, making it an excellent choice for homeowners looking to enhance their outdoor living spaces with a reliable and attractive roofing solution.

Technical Information

Delivery: Lead time 3-5 working days
Delivery: Lead time 3-5 working days
Weight : 8.10 Kg
Brand Name: Brett Martin
Colour: Clear
Material: Polycarbonate
Guarantee: 10 Years Manufacturers
Weight : 8.10 Kg
Brand Name: Brett Martin
Colour: Clear
Material: Polycarbonate
Guarantee: 10 Years Manufacturers

Delivery & Returns

Delivery

The despatch timings we publish are estimates and due consideration needs to be made when making purchases with tight deadlines and as such we shall not be liable for any losses, costs, damages, charges, or expenses caused by any delay for delivery of the goods.

Returns Policy For Brissco Online

We appreciate that there may be occasions you may wish to return items. To help you with this process please see our returns policy below.

Returning an item – Damaged

In the event you receive damaged goods we will arrange a replacement item for you. However, it is your responsibility to notify us within 72 hours of receipt that an item has been received damaged (please see risk below).

Returning an item – Risk

On receipt of the delivery you, the customer, are responsible for those goods and any loss or damage to the goods shall be at your own risk.

Returning an item – Incorrect

If you receive incorrect goods it is your responsibility to notify us within 72 hours of receipt at which point we will make the necessary arrangements.

Delivery shortages

Firstly, our carrier delivers parcels/packages. Any shortages of them must be reported to the driver on receipt. Secondly, shortages of contents of the parcel(s)/package(s) against the enclosed Brissco advice note must be made within 72 hours.

PDFs

Clickloc brochure.pdf

FAQs

What is the Clickloc system?

The Clickloc system is a user-friendly roofing solution consisting of 16mm thick polycarbonate sheets designed for DIY installation on structures such as car ports, canopies, verandas, and pergolas. It eliminates the need for glazing bars by featuring panels that click together for a seamless roof.

What are the main benefits of the Clickloc polycarbonate sheets?

The Clickloc sheets are lightweight, impact-resistant, and come with UV protection. They are easy to handle, offer a quick assembly time, and are durable for long-lasting use.

Are Clickloc panels difficult to install?

No, Clickloc panels are designed for easy DIY installation. You simply cut the panels to the required length, secure them in place using the clickloc channel washer, and click and lock them together.

How do Clickloc panels protect against UV radiation?

These panels are supplied with a UV protection layer on the top surface to extend their lifespan and maintain their condition.

What is the size and thickness of the Clickloc panels?

The panels have a 16mm 5 Wall X-Structure thickness, with a panel width of 528mm and a cover width of 500mm.

What is the U-Value of Clickloc panels?

The U-Value, which measures how well a product insulates, is 2.0W/m²K for these panels.

How much light do the frosted clear panels transmit?

The frosted clear panels allow 66% light transmission, providing a balance of natural light and protection.

What are the recommended purlin center distances for different load capacities?

For a 1000N/m² load, the recommended purlin centers are 800mm. For a 750N/m² load, it's 1000mm, and for a 500N/m² load, it's 1200mm.

What is the minimum roof pitch for Clickloc panel installation?

The minimum roof pitch for these panels is 5°, ensuring proper water drainage and structural integrity.
